Savaria Prolift Vertical Platform Lift

Savaria Prolift Vertical Platform Lift

The Prolift vertical platform lift is a smooth, quiet and efficient operation lift that can be installed in an existing or new structure. Its durable design and the wide variety of options to choose from make it a great affordable lift that meets your accessibility requirements.

Savaria offers two versions of the Prolift: Standard (SCL) and Heavy Duty (HD) that features a higher capacity (up to 1400 lb).

The Savaria Prolift can be configured to travel up to 14′  with as many as 4 stops. With a hydraulic drive, the Prolift is a reliable and quiet system suitable for use in places of worship, schools and other public buildings. Finished in melamine or optional plastic laminate and stainless fixtures, the Prolift can be sized with an interior cab of up to 36″W x 60″L (SCL) or 48″W x 60″L (HD).

Technical Information

PROLIFT SCL

Applications: Commercial, residential, indoors

Standard Capacity:  750 lb (340 kg)

Optional Capacity: 1000 lb (454 kg), where permitted by code.

Maximum Travel: 14′ (426 cm) USA

Nominal Speed: 30 ft/min (0.15 m/s)

Drive/Motor: 1:2 cable hydraulic drive, 3 hp submersed

Minimum Pit: 8″ (203 mm)

Minimum Overhead Clearance: 92″ (2337 mm)

Power Supply: 208 volt, three phase, 60 Hz, 30 amps or 230 volt, single phase, 60 Hz, 40 amps

PROLIFT HD

Applications: Commercial, residential, indoors

Standard Capacity: 1000 lb (454 kg)

Optional Capacity: 1400 lb (635 kg)

Maximum Travel: 14′ (426 cm) USA, where permitted by code.

Nominal Speed: 30 ft/min (0.15 m/s)

Drive/Motor: 1:2 cable hydraulic drive, 5 hp submersed

Minimum Pit: 12″ (305 mm)

Minimum Overhead Clearance: 96″ (2438 mm)

Power Supply: 208 volt, three phase, 60 Hz, 30 amps or 230 volt, single phase, 60 Hz, 40 amps
